Tricab BVA-PAXD/3C1.5BK 3x1.5mm² SHF-1 Marine Cable

Tricab BVA-PAXD/3C1.5BK 3x1.5mm² SHF-1 Marine Power Cable

The Tricab BVA-PAXD/3C1.5BK is an ultra-flexible, high-grade 3-core 1.5mm² marine and offshore low-voltage power cable rated for 0.6/1 kV operating service up to 90°C. Engineered specifically for commercial vessels, naval ships, offshore rigs, and tight vessel wiring chases, it features Tinned Annealed Copper Wire (TACW) conductors for maximum corrosion resistance against marine atmosphere and moisture.

The cable is insulated and jacketed with Low Smoke Zero Halogen (LSZH) SHF-1 compounds compliant with IEC 60092-350, IEC 60332-3-22 Cat A flame propagation standards, and IEEE-45 marine installation benchmarks. With an extraordinary minimum bending radius of just 26 mm, the BVA-PAXD series is designed to eliminate installation stress, bending fatigue, and space constraints behind helm panels, engine compartments, and crowded cable trays.

Key Features

• Extreme Bend Radius Efficiency: Features an industry-leading minimum bending radius of 26 mm, permitting tight turn routing without risking sheath tearing or internal conductor strain.

• TACW Corrosion Resistance: Tinned annealed copper strands stop tarnish, marine oxidation, and galvanic degradation at crimps and terminal blocks.

• Fire Safety Compliant (LSZH): Meets IEC 60332-3-22 Category A flame propagation and IEEE-45 standards; releases non-corrosive, low-smoke gases in the event of fire.

• SHF-1 Thermoplastic Outer Sheath: Offers excellent protection against UV exposure, humidity, lubricants, and mechanical abrasion in shipboard environments.
