B&G
B&G - 000-12365-001 - B&G ZC2 Wired Remote Controller
B&G - 000-12365-001 - B&G ZC2 Wired Remote Controller
Low stock: 1 left
Regular price
$ 599.00 USD
Regular price
$ 599.00 USD
Sale price
$ 599.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
B&G ZC2 remote
SKU: 000-12365-001
Perfectly designed for mounting in a cockpit pedestal, by the chart table or in other locations suiting a ‘portrait’ orientation. The B&G ZC2 Remote Controller provides intuitive keypad and rotary-dial command of up to six Zeus², Zeus³, Glass Helm or Vulcan multifunction displays; and can be used to control a B&G autopilot via any networked display.
Key Features
- Control up to six Zeus², Zeus³, Glass Helm or Vulcan multifunction displays
- Autopilot remote control via any networked display
- High-quality aluminium control dial with built-in cursor functions
- MOB function
- Portrait orientation (landscape version also available)
- Narrow design perfect for chart table mounting
- Dash mount with low 8mm profile
- Zero-profile flush mount with optional bracket
- Integrated high-decibel speaker for critical alarms
- Quickly switch displays with dedicated button and LED indicators
- Single NMEA 2000® connection
Specifications
Connectivity
- NMEA 2000 Connectivity1 x NMEA2000 Micro-C port, 2 LEN
Approvals
- Approvals ComplianceIEC/EN 60945
Electrical
- Power Consumption max1.0W
- Power Consumption min0.5W
- Power Consumption typical0.6W
- Recommended Fuse Rating5A
- Supply Voltage12V DC (10-16V DC)
Environment
- HumidityUp to 95% RH
- Operating Temperature Range-15°C to +55°C (5°F to 131°F)
- Waterproofrating IPx6
Physical
- Compass Safe200mm (0.9')
- Dimensions W x H x D60 x 150 x 45mm (2.4 x 5.9 x 1.8")
- Mounting TypeFlush
- Weight0.3 kg (0.66 Lbs)
Other
- Interfacekeypad
- Warranty Period 2 years
-
N2K-T-RD Network T-Connector
-
OP50/ZC2 Keypad Sun Cover
-
ZC2 Dash Kit (Gasket Bezel Screw)
